Low speed automatic fish feeder

Automatic Fish Feeder

Do you have to worry about low survival and low production in your Fish Farming pond?

Do you worry about the high incidence of water pollution?

Are you still troubled by the daily feed management?

Then you may need our Automatic Fish Feeder!

Product Introduction:

Automatic Fish feeder is fishery feeding machine for fish pond. Feed in hopper is evenly discharged into the dispensing part by the detaching part when the feeder is working. The dispensing part throws the feed into the fish pond evenly and quickly under centrifugation from main motor.

This machine can replace artificially automatic timing, quantitative spraying various specifications of the granule feed stuff feed the fish. The machine because use principle of vibration type unloading, fundamentally solve the unloading process in other models produced during the problems, such as card materials, turn blocking fault.

The machine working is reliable, accurate, and shooting, material feeding distance, large area, simple structure, convenient maintenance, save electricity artificial feed, using three months you can withdraw cost.

Specification:

Model	QH-120Z
Speed	1400r/min
Working Voltage	220V/AC
Motor power	120W
Feeding distance	≥12m
Feeding Capacity	Adjustable from 1 to 18 gear shifts
Feeding time	Adjustable from 1 to 18 seconds
Feeding interval	Adjustable from 1 to 18 seconds
Fully automatic period	Can set up to 8 time slots Max
Feeding angle	≥120°
Feeding area	140m2
Feeding tank capacity	Sinking material feeder:80kg Puffed material feeder：25-40kg
Maximum feeding amount	10 minutes / packages (adjustable)
Dimension	565680CM

Advantages:

1. Stable physical properties, high temperature resistance to 110 ℃, mold production for parts, standardized assembly line operations.

2. The body is made of new PP plastic, which is thicker and upgraded, more durable; anti-aging, leakage-proof and safer.

3. Electromagnet vibrating throwing feeds, precise control and durable.

4. Over sized bell mouth feeding design, feeding fan angle is larger; throwing feeds is wider and more uniform.

5. Using 2800 rpm high-speed copper motor, the feeding distance is longer and more durable.

6. The feeding mechanism is stable and there is no leakage.

7. The throwing disc is made of plastic mold inlaid steel sheet. its well balanced when the high -speed motor running, it won’t cause any vibration due to the imbalance of the throwing disc, which will not stop throwing feeds.

8.The sensor install on the vibration plate to prevent it from dust accumulation which will cause the feeder to not have the function of “automatic induction detection of feed”.

9. The high quality touch-button controller solves the problem of press broken the controller’s label in the past, and its performance is much higher than that of other potentiometers types feeder which manufactures by other factories.

10. Famous brand”Double Bearing” on each side of output shaft, wide gear wheel used to provide better
torque output and durability.
